Thank you for being part of this project!

We have some files for you

Click to download the PDF drawing of the Clamps

Drawing
Model

Hardware

Here's a list of all the hardware we used to manufacture the Focus Clamps. We want you to have full autonomy in maintaining your Focus Clamps.

Code
Short Description
Link
9528K15
1/4" Diameter - 52100 Alloy Steel Ball
Link to the part
91294A237
M6x1 - 14 Long - Flat Head Screw - Hex Drive
Link to the part
92695A827
1/2"-20 - 1-3/4" Long - Cone-Point Set Screw
Link to the part
9528K19
3/8" Diameter - 52100 Alloy Steel Ball
Link to the part
9657K608
Compression Spring 0.25" Long, 0.210" OD, 0.158" ID
Link to the part
94414A714
M3x0.50 - 10 Long - Flat Head Screws - Torx
Link to the part
94414A711
M3x0.50 - 5 Long - Flat Head Screws - Torx
Link to the part
